1. Integrated stator assembly:
1. Loading of stator core and assembly of wire bridge
2. Winding machine
3. Manual wire cutting and installation of copper bars
4. Mechanical arm copper bar welding
5. Shell coding and pressing installation
6. Coating the outer shell with oil and assembling the bearings
7. Flow to the electro-hydraulic machine assembly
2. Integrated rotor assembly:
1. Mechanical arm picking and assembly+manual loading and assembly
2. Press the rotor shaft into the rotor core and magnetize the rotor
3. Press bearings at both ends of the rotor into place
4. Flow to the motor assembly station
3. Integrated motor assembly:
1. The mechanical arm takes and assembles the rotor assembly and stator assembly by manually loading materials.
2. Press fit
3. The controller is installed on the motor body
4. Tighten the product housing with screw driver
5. Flow to the electro-hydraulic pump assembly
4. Electro-hydraulic pump assembly:
1. Mechanical arm picking and assembly+manual loading and assembly
2. Three axis dispensing machine
3. Cover plate pressing installation
4. Laser marking
5. Tighten the product housing with screw driver
