Cycle Time (C/T): ≤40s
Annual Capacity: ≥490,000 units
Yield Rate: ≥98%
Manpower: ≤12 operators
Footprint: 37,000mm × 8,900mm
Main workstation introduction:
Guide Sleeve Assembly
Valve Body Riveting Steel Ball
Bearing Press-Fitting
Master Cylinder Cup Assembly
Solenoid Valve & Pressure Sensor Press-Fitting
Cup Assembly with PFS & Air Tightness Test
Boost Cylinder & Electric Drive Assembly
Lips Calibration Readback Test
Solenoid Valve Comprehensive Performance Test
HCU Assembly Comprehensive Performance Test
Inspection & Assembly of Reservoir Tank Assembly
EOL (End-of-Line) Performance Test
Push Rod Fork Assembly
WCBS Assembly Packaging & Offline
